– Specification
| [ Specification ]
• Type : Ultraviolet and Infrared • Detection Range : 100ft(30m) for N-Heptane fire • Field of View : Horizontal 90°, Vertical 90° • Temperature Range Operating : -40℃ to +75℃ • Storage : -50℃ to +80℃ • Humidity Range : 0 to 95% relative humidity • performance : FM3260, EN 54-10(CPR) • Explosion proof : – Ex d IIB+H2 T6 IP67(KGS) – Class I Division 1 Groups B,C and D(FMUS) – Class II/III Division 1 Groups E,F and G(FMUS) – T6: -40°F(-40°C) to +176°F(+75°C)(FMUS) – IP67/NEMA 4X(FMUS) – II 2 G Ex db IIB+H2 T6(ATEX) – Ex db IIB+H2 T6(IECEx) • water tight : IP67(KGS) • Output – Relay · Fire Alarm, Fault Alarm, Warning Alarm · From A or B Selectable, 28VDC, 2A – 4-20mA – RS-485 |
[ Structure ]
• Dimensions : W134 x H117 x D120 (mm) W5.3 x H4.6 x D4.7 (inch) • Enclosure Material : Stainless steel 316 • Shipping Weight : 3.4 kg • Color : Metal • Conduit Entry Size : 2 x 1/2 inch NPT, M20X1.5 [ Electrical ] • Operating Voltage : Typical DC24V (17 to 32) • Power Consumption : 2.0W minimum / 3.6W maximum at 32 VDC • Wiring : 14AWG(2.08mm2) to 24AWG(0.205mm2) shield cable recommended. • Electromagnetic Compatibility : EMC Protected |
